955.17 车身及附件 Vehicle Body and Accessory

1 955.17.1 1 随机备件工具箱 Spare part tool box 1 9550005-
2 Z50B.17.1A 1 右前挡泥板总成 R front dishboard 1 9550005-
3 Z50B.17-3 1 撑铁 Block 2 9550005-
4 Z50B.17.6 1 前右扶手 R front hand rail 1 9550005-
5 Z50B.17.5A 1 梯子 Ladder 2 9550005-
6 Z50F.17.3 1 右踏板 Right pedal 1 9550005-
7 Z50E.37.3 1 后右扶手 Right handrail 1 9550005-
8 Z50E.37A.1 1 发动机护罩 Engine hood 1 9550005-
9 Z50E.37.8 1 左反光镜支架 L reflector supporting 1 9550005-
10 Z50E.37.9 1 右反光镜支架 R reflector supporting 1 9550005-
11 Z50E.37.4 1 后左扶手 Left handrail 1 9550005-
12 Z50E.37.5 1 左踏板 Left pedal 1 9550005-
13 Z50B.17.7 1 前左扶手 L front hand rail 1 9550005-
14 Z50E.37-1 1 撑铁 Block 2 9550005-
15 Z50E.17F-3 1 垫圈 Washer 3 9550005-
16 Z50B.17.2A 1 左前挡泥板总成 L front dash board 1 9550005-
17 B-G057830-00030 1 螺栓 M12x25ZnD Bolt 29 9550005-
18 B-G000930-00003 1 垫圈 12 Washer 47 9550005-
19 B-G061700-00007 1 螺母 M12ZnD Nut 4 9550005-
20 B-G00097B-00004 1 垫圈 12ZnD Washer 34 9550005-
21 B-G057830-00034 1 螺栓 M12x30ZnD Bolt 12 9550005-
22 B-G057830-00041 1 螺栓 M12x40ZnD Bolt 2 9550005-
23 B-G057830-00043 1 螺栓 M12x45ZnD Bolt 2 9550005-
24 B-G057830-00143 1 螺栓 M8x25ZnD Bolt 12 9550005-
25 B-G000930-00003 1 垫圈 8 Washer 12 9550005-
26 B-G061700-00036 1 螺母 M8ZnD Nut 12 9550005-
27 B-Q0202490-00003 1 垫圈 12ZnD Washer 10 9550005-
28 W-09-00023 1 室外反光镜 Viewfinder 2 9550005-
29 Z50E.37.1.2 1 左门 L.Door 1 9550005-
30 Z50E.37.1.3 1 右门 R.Door 1 9550005-
31 Z50B.12.9.3 1 搭扣总成 Agraffe 1 9550005-
32 Z50E.37.1.4 1 格栅 Grille 1 9550005-
33 Z40E.17F.1.5 1 板 Plate 1 9550005-
34 Z50E.37.1-1 1 板 Plate 2 9550005-
35 Z50E.37.1.5 1 板 Plate 1 9550005-
36 B-G057830-00030 1 螺栓 M12x25ZnD Bolt 12 9550005-
37 B-G057820-00179 1 螺栓 M8X35ZnD Bolt 4 9550005-
38 B-G00097B-00023 1 垫圈 8ZnD Washer 8 9550005-
39 B-G000910-00025 1 开口销 3.2x16ZnD Pin 8 9550005-
40 B-G00097B-00002 1 垫圈 10ZnD Washer 8 9550005-
41 B-G057830-00006 1 螺栓 M10x25ZnD Bolt 4 9550005-
42 B-G000930-00001 1 垫圈 10 Washer 4 9550005-
43 B-G008820-00046 1 销轴 B8x40 Pin shaft 4 9550005-
44 W-09-00014 1 气弹簧/JY2307 Air spring 2 9550005-
45 Z50B.17.3.2.2 1 铰链 Hinge 4 9550005-
46 Z50B.17.3.6-8 1 支座 Support 4 9550005-
47 B-G030810-00003 1 热镀锌钢丝 II-5 Wire 1 9550005-
48 W-09-00030 1 锁|NBS504 Lock 2 9550005-
