47C0783(A) 椅座 SEAT STAND

01 02D2258 002 支承座 BRACKET 1
02 04B0049 000 螺钉 SCREW 4
03 06B0086 000 垫圈 WASHER 8
04 34C0220 001 座椅滑道 SLIDE TRACK 1
05 00B0085 000 螺栓 BOLT 4
06 06B0006 000 垫圈 WASHER 6
07 06B0005 000 垫圈 WASHER 6
08 00D2971 000 司机椅座 SEAT BRACKET 1
09 04B0174 000 螺钉 SCREW 4
10 00B0020 000 螺栓 BOLT 2
11 21A2803 000 弯板 PLATE 2
12 06B0024 000 垫圈 WASHER 4
13 03B0014 000 螺钉 SCREW 4 00B0022
13 00B0022 000 螺栓 BOLT 4 S/N 60779-Up
14 86A0369 002 盖板 COVER 1 27A0826
14 27A0826 000 前盖板 PLATE 1 S/N 60779-Up
15 06B0003 000 垫圈 WASHER 4
