倒 2 档轴 Shaft assembly

1 倒退 2 档轴组件 SHAFT AS JB3263018 1
2 挡圈 RING-RETAINING JB326379800 6
3 止推片 DISC-THRUST JB326379100 2
4 挡圈 RING-RETAINING JB326078500 2
5 前进低速和倒退档齿轮 GEAR(55 TEETH) JB326068102 1
6 前进低速和倒退档齿轮毂组件 HUB AS JB326078200 1
6A 前进低速和倒退档齿轮毂 HUB JB326496503 1
6B 滑动轴承 BEARING-SLEEVE JB326296402 1
7 挡圈 RING-RETAINING JB326068200 2
8 离合器压板 PLATE-END JB326378403 2
9 从动片 PLATE-CLUTCH JB326083803 16
10 波形弹簧 SPRING-WAVE JB326068300 2
11 活塞 PISTON JB326068801 2
12 从动片 DISC-FRICTION JB326375800 2
13 2/3 档齿轮毂组件 HUB AS JB328619700 1
13A 滑动轴承 BEARING-SELEEVE JB326296402 1
14 2 档齿轮 GEAR(49 TEETH) JB326378602 1
15 套筒组件 SPACER AS JB326378200 1
16 倒退 2 档轴 1 档齿轮 GEAR(32 TEETH) JB326075602 1
17 旋转密封圈 RING-SEAL JB326068600 3
18 止推片 DISC-THRUST JB326378801 1

19 挡圈 WASHER JB326370901 1
20 止推片 DISC-THRUST JB326378701 2
21 挡圈 RETAINER JB326379900 2
22 平衡活塞组件 SEAL AS-BALANCE JB326377700 2
23 主动摩擦片 DISC AS-FRICTION JB326380101 18
24 旋转密封圈 RING-SEAL JB326299200 2
25 旋转密封圈 RING-SEAL JB326299100 2
