液力变矩器（I）Torque Converter（I）

1 Z30.2.3.1-7 1 螺套 Plug 2 00005-
2 Z30.2.3.1-6 1 垫圈24 Washer 4 00005-
3 B-G061730-00012 1 螺母M24X1.5 Nut 2 00005-
4 Z30.2.3.1-5 1 螺塞 Plug 2 00005-
5 Z30.2.3.2-3 1 大弹簧 Big spring 1 00005-
6 Z30.2.3.2-2 1 小弹簧 Small spring 1 00005-
7 Z30.2.3.2-4 1 阀芯 Valve core 1 00005-
8 Z30.2.3.2-1 1 阀体 Valve body 1 00005-
9 Z30.2.3-31 1 密封垫 Seal washer 1 00005-
10 B-G000930-00001 1 垫圈10 Spring washer 6 00005-
11 B-G000700-00010 1 螺钉M10×65 Screw 6 00005-
12 Z30.2.3-29 1 密封垫 Seal washer 1 00005-
13 Z30.2.3.1-2 1 阀体 Valve body 1 00005-
14 Z30.2.3.1-1 1 阀芯 Valve core 1 00005-
15 Z30.2.3.1-4 1 小弹簧 Small spring 1 00005-
16 Z30.2.3.1-3 1 大弹簧 Big spring 1 00005-
17 Z30.2D.1-17 1 密封垫 Seal washer 1 00005-
18 Z30.2D.1-16 1 盖板 Cover board 1 00005-
19 B-G000930-00017 1 垫圈8 Spring washer 4 00005-
20 B-G057830-00137 螺栓M8X16ZnD Bolt 4 00005-
21 Z30.2.3-30 1 螺塞 Plug 2 00005-
22 B-G008250-00001 1 螺钉M16 Screw 1 00005-
23 B-J010020-00010 1 垫圈30 Spring washer 1 00005-
24 Z30.4.16-1 1 通气杯 Aerated cup 1 00005-
25 Z30.4.16-2 1 杯盖 Cup cover 1 00005-
26 B-Q020710-00064 1 O形圈40×3.5 O-ring 1 00005-
27 Z30.4.16.1 1 过滤盘 Filtering dish 1 00005-
28 B-G00895A-00001 1 挡圈 40 Snap ring 1 00005-
29 Z30.4.16-3 1 外套 Outer sleeve 1 00005-
30 Z30.2.3-45 1 标牌 Scutcheon 1 00005-
31 B-G008270-00005 1 铆钉2X6 Rivet 4 00005-
32 B-G000930-00003 1 垫圈12 Spring washer 12 00005-
33 B-G061700-00007 1 螺母M12 ZnD Nut 6 00005-
34 B-G057830-00034 1 螺栓M12×30 ZnD Bolt 6 00005-
35 B-G057830-00045 1 螺栓M12×50 ZnD Bolt 6 00005-
36 Z30.2D.1-1 1 箱体 Case 1 00005-
37 Z30.2D.1-20 1 纸垫 Paper pad 1 00005-
38 B-G000700-00006 1 螺钉M10X35 Bolt 12 00005-
39 B-G000930-00001 1 垫圈10 Spring washer 12 00005-
40 Z30.2D.1-7 1 连接壳体 Case 1 00005-
41 Z30.2D.1-15 1 密封垫 Seal washer 1 00005-
42 B-J010020-00008 1 垫圈24 Washer 2 00005-
