液力变矩器（II）Torque Converter（II）

1 B-G057820-00021 1 螺栓 M10X65ZnD Bolt 8 00005-
2 B-J010020-00001 1 垫圈10 Washer 8 00005-
3 Z30.2.3-13 1 轴承盖 Bearing cover 1 00005-
4 Z30.2.3-14 1 垫 Washer 1 00005-
5 B-G09877A-00025 1 油封FB55X80X12 Oil seal 1 00005-
6 B-G00893A-00001 1 挡圈100 Snap ring 1 00005-
7 B-G00894A-00019 1 挡圈55 Snap ring 1 00005-
8 B-G002760-00021 1 轴承6211 Bearing 1 00005-
9 Z30.2.3-12A 1 密封环 Seal ring 1 00005-
10 Z30.2.3-12B 1 密封环 Seal ring 1 00005-
11 Z30.2.3-15 1 垫 Washer 1 00005-
12 Z30.2D.1-4 1 导轮座 Stator 1 00005-
13 Z30.2.3-9A 1 密封环 Seal ring 1 00005-
14 Z30.2.3-9B 1 密封环 Seal ring 1 00005-
15 B-G001190-00019 1 销A8×16 Pin 3 00005-
16 Z30.2.3-18 1 垫片 Washer 2 00005-
17 B-G000930-00017 1 垫圈8 Washer 22 00005-
18 B-G000700-00036 1 螺钉M8×25 Screw 6 00005-
19 Z30.2D.1-19 1 垫 Washer 1 00005-
20 Z30.2D.1-5L 1 齿轮 Gear 1 00005-
21 Z30.2.3-20 1 垫 Washer 1 00005-
22 Z30.2.3-7 1 垫片 Washer 4 00005-
23 B-G057830-00140 1 螺栓M8×25 Bolt 16 00005-
24 Z30.2D.1-3 1 涡轮轴 Turbine 1 00005-
25 Z30.2D.1-6 1 油盘盖 Cover 1 00005-
26 B-G000930-00015 1 垫圈 6 Washer 10 00005-
27 B-G000700-00030 1 螺钉M6×12 Screw 10 00005-
28 Z30.2.3-17 1 挡圈 Snap ring 1 00005-
29 B-G002760-00012 1 轴承61918 Bearing 2 00005-
30 Z30.2D.1-18 1 隔圈 Disconnecting ring 1 00005-
31 Z30.2D.1-2 1 隔套 Disconnecting cover 1 00005-
32 B-G00894A-00018 1 挡圈52 Snap ring 1 00005-
33 B-G002760-00027 1 轴承6308N Bearing 1 00005-
34 B-G00894A-00025 1 挡圈90 Snap ring 2 00005-
35 Z30.2.3-34 1 压板 Clamping 1 00005-
36 B-G001190-00016 1 销A6×16 Pin 1 00005-
37 B-G000930-00003 1 垫圈12 Washer 1 00005-
38 B-G057830-00041 1 螺栓M12×40ZnD Bolt 1 00005-
