变速箱体及附件（Ⅰ）  Transmission and Accessories（Ⅰ）

1 Z30.4.18 1 档位压力表油管总成 Clutch pressure gauge tube ass’y 1 00005-
2 B-G001190-00027 1 销D5×40 Pin 1 00005-
3 B-J010000-00011 1 螺塞M27×2 Plug 1 00005-
4 Z30.4.14A.1 1 油尺套筒 Sleeve 1 00005-
5 Z30.4-1 1 变速箱体 Case 1 00005-
6 Z30.4.15-1 1 支承板 Support 2 00005-
7 B-G057820-00087 1 螺栓M16×70 ZnD Bolt 4 00005-
8 B-G000930-00006 1 垫圈16 Washer 4 00005-
9 Z30.4.14-5 1 拧紧螺杆 Screw 1 00005-
10 Z30.4.14-4 1 盖 Cover 1 00005-
11 Z30.4.14-3 1 油封 Seal oil 1 00005-
12 Z30.4.14.1 1 油尺组件 Oil gauge ass’y 1 00005-
13 B-Q020710-00029 1 O型密封圈20×2.4 O-ring 2 00005-
14 Z30.4-2 1 密封纸垫 Gasket 1 00005-
15 B-J010020-00003 1 垫圈14 Washer 5 00005-
16 B-G057820-00003 1 螺栓M10×110ZnD Bolt 3 00005-
17 Z30.4-3A 1 变速箱盖 Tranmission cover 1 00005-
18 B-G00097B-00002 1 垫圈10 ZnD Washer 3 00005-
19 B-Q020710-00008 1 O型圈11×1.9 O-ring 4 00005-
20 Z30.4.16-3 1 外套 Outer sleeve 1 00005-
21 B-G00895A-00001 1 挡圈40 Snap ring 1 00005-
22 Z30.4.16.1 1 过滤盘 Fender 1 00005-
23 B-Q020710-00064 1 O形圈40×3.5 O-ring 1 00005-
24 Z30.4.16-2 1 杯盖 Cap 1 00005-
25 B-G008270-00005 1 铆钉2×6 Screw 4 00005-
26 Z30.4.16-1 1 通气杯 Breather 1 00005-
27 B-J010020-00010 1 垫圈30 Washer 1 00005-
28 B-G001180-00001 1 销A10×35 Cone pine 2 00005-
29 Z30.4.17-3 1 管接头 Joint 4 00005-
30 B-J010020-00006 1 垫圈20 Washer 10 00005-
31 B-G000930-00001 1 弹簧垫圈10 Spring washer 24 00005-
32 Z30.4.17-5 1 冷却油分流器 Diverter 1 00005-
33 B-G057820-00162 1 螺栓M8×50ZnD Bolt 3 00005-
34 B-G000930-00017 1 垫圈8 Washer 3 00005-
35 B-G00097B-00023 1 垫圈8ZnD Washer 3 00005-
36 B-J010020-00009 1 垫圈27 Washer 1 00005-
37 Z30.2M.4-1 1 接头体22/M27×2 Joint body 1 00005-
38 B-G00097B-00008 1 垫圈16ZnD Washer 4 00005-
39 B-G057820-00038 1 螺栓M12×45ZnD Bolt 12 00005-
40 B-G057830-00037 1 螺栓M12×35ZnD Bolt 4 00005-
