前进/倒退档轴总成  Forward and Reverse Gear Ass’y

1 Z30.4.1-20 1 进油轴承盖 Bearing cover 1 00005-
2 Z30.4.1-18 1 垫 Spacer 1 00005-
Z30.4.1-18B 1 垫 Spacer 1 00005-
Z30.4.1-18C 1 垫 Spacer 1 00005-
3 B-Q020710-00029 1 O形圈20×2.4 O-ring 2 00005-
4 Z30.4.1-22B 1 油封环 Seal ring 2 00005-
5 B-G00894A-00015 1 挡圈45 Snap ring 1 00005-
6 B-G002760-00018 1 轴承6209 Bearing 1 00005-
7 Z30.4.1-17 1 套 Sleeve 1 00005-
8 B-G003010-00002 1 轴承8110 Thrust bearing 2 00005-
9 Z30.4.1-2 1 隔套 Shaft sleeve 1 00005-
10 W-03-00007 1 滚针轴承9243/55 Needle bearing 2 00005-
11 Z30.4.1-3L 1 倒退档齿轮 Reverse clutch gear 1 00005-
12 Z30.4.1-16 1 挡圈 Snap ring 4 00005-
13 Z30.4.1-11 1 盖板 Cover 2 00005-
14 Z30.4.1-4 1 主动片 Drive disc 16 00005-
15 Z30.4.1-6 1 波形弹簧 Wave spring 32 00005-
16 Z30.4.1-5 1 从动片 Drive disc 16 00005-
17 Z30.4.1-9 1 压板 Holder 2 00005-
18 B-G003010-00003 1 轴承8111 Thrust bearing 2 00005-
19 Z30.4.1-8A 1 活塞 Piston 2 00005-
20 B-G000780-00006 1 螺钉M12×12 Screw 2 00005-
21 Z30.4.1-19 1 油封环 Seal ring 4 00005-
22 932.4.1-1 1 前进倒档轴 F-R shaft 1 00005-
23 Z30.4.1-10 1 齿圈 Gear ring 1 00005-
24 Z30.4.1-7AL 1 缸体 Cylinder body 1 00005-
25 Z30.4.1-12L 1 前进档齿轮 Gear 1 00005-
26 Z30.4.1-13 1 轴承隔套 Spacer sleeve 1 00005-
27 B-G002760-00019 1 轴承210 Bearing 1 00005-
28 W-15-00502 1 油封AE2857E0(NOK) Oil seal 1 00005-
29 Z30.4.1-14 1 垫 Washer 1 00005-
Z30.4.1-14B 1 垫 Washer 1 00005-
Z30.4.1-14C 1 垫 Washer 1 00005-
30 Z30.4.1-15A 1 轴承盖 Bearing cover 1 00005-
31 B-G057830-00007 1 螺栓M10×28 ZnD Bolt 12 00005-
32 B-G000930-00001 1 垫圈10 washer 12 00005-
33 Z30E.4.1-8A 1 输入法兰 Flange 1 00005-
34 B-Q020710-00166 1 O形圈50×5.7 O-ring 1 00005-
35 Z50B.4.1-6 1 垫圈 Washer 1 00005-
36 B-G008580-00009 1 垫圈24 Washer 1 00005-
37 B-G008120-00008 1 螺母M24×1.5 Nut 1 00005-
