二、三档轴总成 2nd and 3rd Shaft Ass’y
二、三档轴总成 2nd and 3rd Shaft Ass’y
1 B-G057830-00007 1 螺栓M10×28 ZnD Bolt 12 00005-
2 B-G000930-00001 1 垫圈10 Washer 12 00005-
3 Z30.4.4A-9 1 轴承盖 Bearing cover 1 00005-
4 Z30.4.4-10 1 密封纸垫 Washer 1 00005-
5 B-G00894A-00015 1 轴用弹性挡圈45 Snap ring 2 00005-
6 B-G002830-00001 1 滚动轴承NJ2309 Bearing 1 00005-
7 Z30.4.4A-2L 1 一档从动齿轮 1st driven gear 1 00005-
8 Z30.4.4-3L 1 输出轴主动齿轮 Drive gear 1 00005-
9 B-G003010-00003 1 轴承8111 Thrust bearing 3 00005-
10 W-03-00007 1 轴承9243/55 Needle bearing 3 00005-
11 Z30.4.4-4L 1 二档离合器齿轮 2nd clutch gear 1 00005-
12 Z30.4.4-5 1 二、三档齿圈 2nd and 3rd gearring 1 00005-
13 Z30.4.4A-1 1 二、三档离合器轴 Shaft 1 00005-
14 Z30.4.1-19 1 油封环 Oil seal ring 4 00005-
15 B-G000780-00006 1 螺钉M12×12 Screw 2 00005-
16 Z30.4.1-8A 1 活塞 Piston 2 00005-
17 Z30.4.1-7AL 1 缸体 Cylinder body 1 00005-
18 Z30.4.1-16 1 挡圈 Snap ring 4 00005-
19 Z30.4.1-9 1 压板 Holder 2 00005-
20 Z30.4.1-6 1 波形弹簧 Wave spring 34 00005-
21 Z30.4.1-4 1 主动片 Drive disc 17 00005-
22 Z30.4.1-5 1 从动片 Driven disc 17 00005-
23 Z30.4.1-11 1 盖板 Hood 2 00005-
24 Z30.4.4-6L 1 三档离合器齿轮 3rd clutch gear 1 00005-
25 B-G003010-00001 1 轴承8109 Thrust bearing 1 00005-
26 B-G002760-00029 1 轴承6309 Bearing 1 00005-
27 Z30.4.1-22B 1 油封环 Seal ring 2 00005-
28 Z30.4.4-8 1 垫 Washer 1 00005-
29 Z30.4.4-7 1 二、三档进油轴承盖 Bearing cover 1 00005-
30 Z30.4.4A-11 1 螺堵 Plug 1 00005-
