958.14  工作液压系统  Hydraulic System

1 958.14.1 1 油箱 Oil tank 1 9580005-
2 958.14.2 1 油箱回油管 Tube 1 9580005-
3 958.14.3 1 油箱出油管 Tube 1 9580005-
4 958.14-1 1 低压胶管 Hose 2 9580005-
5 958.14.4 1 软管总成 Hose ass’y 1 9580005-
6 958.14.5 1 油泵进油管 Tube 1 9580005-
7 958.14.6 1 油泵出油管 Tube 1 9580005-
8 958.14.7 1 回油块 Joint 1 9580005-
9 958.14-2 1 板 Plate 1 9580005-
10 Z40H.14B.17 1 接头 Joint 1 9580005-
11 958.14.8 1 胶管接头 Hose joint 1 9580005-
12 Z50G.14C-2 1 板 Plate 1 9580005-
13 Z50G.14C-3 1 板 Plate 1 9580005-
14 Z50G.14C-4 1 油管夹 Tube clip 2 9580005-
15 Z50G.14C-5 1 油管夹 Tube clip 6 9580005-
16 Z50G.14C-6 1 板 Plate 4 9580005-
17 Z60F.14-9 1 套管 Bushing 2 9580005-
18 Z60F.14-10 1 套管 Bushing 6 9580005-
19 Z50G.14C-7 1 板 Plate 1 9580005-
20 Z50G.14.7 1 软管总成 Hose ass’y 1 9580005-
21 Z50G.34.1 1 动臂油缸 Cylinder 2 9580005-
22 Z50B.14.23 1 油管 Tube 2 9580005-
23 Z50G.14.9 1 支板 Plate 1 9580005-
24 Z50G.14.10 1 支板 Plate 1 9580005-
25 Z50G.14.11 1 油管 Tube 1 9580005-
26 Z50G.14.12 1 油管 Tube 1 9580005-
27 Z50B.14-3 1 板 Plate 2 9580005-
28 Z50B.14-4 1 衬垫 Washing 2 9580005-
29 Z50G.14-11 1 连接板 Plate 1 9580005-
30 958.14.9 1 多路阀进油管 Tube 1 9580005-
31 Z50G.34.2 1 油管 Tube 1 9580005-
32 Z50G.34.3 1 油管 Tube 1 9580005-
33 Z50G.14.16 1 油管 Tube 2 9580005-
34 Z50G.14G.4 1 接头体 Joint 3 9580005-
35 Z50G.14-12 1 O形圈 O-ring 6 9580005-
36 Z50G.34.6 1 油管 Tube 1 9580005-
37 Z50G.34.4 1 转斗油缸 Cylinder 1 9580005-
38 Z50G.14G-3 1 板 Plate 2 9580005-
39 Z50G.14A-1 1 接头 Joint 8 9580005-
40 Z50G.14.21 1 油管 Tube 1 9580005-
41 Z50G.14.22 1 油管 Tube 1 9580005-
42 Z50G.14G-2 1 接头体 Joint 3 9580005-
43 Z50G.14C.11 1 多路阀回油管 Tube 1 9580005-
44 Z60H.10-3 1 纸垫 Paper washing 1 9580005-
45 Z50G.14A-2 1 O形圈 O-ring 8 9580005-
46 958.14.10 1 软管总成 Hose ass’y 1 9580005-
47 958.14.11 1 软管总成 Hose ass’y 1 9580005-

48 Z50G.14P.6 1 油管 Tube 1 9580005-
49 Z30.4M-2 1 接头 Joint 5 9580005-
50 958.14.12 1 软管总成 Hose ass’y 1 9580005-
51 958.14.13 1 软管总成 Hose ass’y 1 9580005-
52 958.14.14 1 油管 Tube 1 9580005-

B-G057830-00143 1   螺栓M8×25ZnD  Bolt    6   9580005-
B-G000930-00017 1   垫圈8 Washer  50  9580005-
B-Q020710-00094 1   O形圈75×3.5   O-ring  1   9580005-
B-G057830-00010 1   螺栓M10×30ZnD Bolt    16  9580005-
B-G000930-00001 1   垫圈10    Washer  60  9580005-
B-Q020710-00099 1   O形圈80×3.1   O-ring  1   9580005-
B-J088700-00020 1   喉箍d90   Clamp   8   9580005-
B-G057830-00033 1   螺栓M12×30-10.9ZnD    Bolt    4   9580005-
B-G000930-00003 1   垫圈12    Washer  8   9580005-
B-Q020710-00077 1   O形圈54×3.5   O-ring  1   9580005-
W-01-00074  1   双联泵|P257B367ILZA20  Gear pump   1   9580005-
B-G057820-00015 1   螺栓M10×50ZnD Bolt    4   9580005-
B-Q020710-00071 1   O形圈48×3.5   O-ring  6   9580005-
B-J010000-00002 1   螺塞M14×1.5   Plug    1   9580005-
B-J010020-00003 1   垫圈14    Washer  7   9580005-
B-G057830-00030 1   螺栓M12×25ZnD Bolt    2   9580005-
B-Q020490-00003 1   垫圈12    Washer  14  9580005-
B-G057830-00132 1   螺栓M6×25ZnD  Bolt    4   9580005-
B-G000930-00015 1   垫圈6 Washer  10  9580005-
B-G061700-00034 1   螺母M6ZnD Nut 8   9580005-
B-Q020710-00066 1   O形圈44×3.5   O-ring  3   9580005-
B-Q020710-00006 1   O形圈11×1.9   O-ring  23  9580005-
B-G061700-00007 1   螺母M12ZnD    Nut 4   9580005-
B-G057820-00158 1   螺栓M6×60ZnD  Bolt    6   9580005-
B-G057830-00034 1   螺栓M12×30ZnD Bolt    6   9580005-
B-G057820-00001 1   螺栓M10×100ZnD    Bolt    2   9580005-
W-16-00140  1   软管总成|F7711515202020 Hose ass’y  1   9580005-
B-Q020140-00003 1   分离式法兰A44.1/21   Flange  18  9580005-
B-G057830-00009 1   螺栓M10×30-10.9ZnD    Bolt    32  9580005-
W-15-00108  1   O形圈|2-222N552-90    O-ring  6   9580005-
B-G057820-00014 1   螺栓M10×50-10.9ZnD    Bolt    4   9580005-
B-G057820-00017 1   螺栓M10×60-10.9ZnD    Bolt    24  9580005-
B-Q020710-00065 1   O形圈41×3.5   O-ring  6   9580005-
B-Q020490-00001 1   垫圈10    Washer  64  9580005-
B-Q020120-00003 1   U形管夹A28 U-clip  8   9580005-
B-G061760-00001 1   螺母M10×1.25ZnD   Nut 22  9580005-
B-G057830-00006 1   螺栓M10×25ZnD Bolt    12  9580005-
B-G057830-00145 1   螺栓M8×30-10.9ZnD Bolt    40  9580005-
B-Q020710-00057 1   O形圈36×3.5   O-ring  2   9580005-
B-G057830-00047 1   螺栓M12×55ZnD Bolt    2   9580005-

B-Q020750-00090 1   胶管接头8I-2600 Hose    3   9580005-
B-G057830-00043 1   螺栓M12×45ZnD Bolt    4   9580005-
B-G061700-00007 1   螺母M12ZnD    Nut 4   9580005-
B-G00097B-00004 1   垫圈12ZnD Washer  4   9580005-
W-07-00169  1   多路换向阀|7130-C79  Valve   1   9580005-
B-G057820-00072 1   螺栓M16×115-10.9ZnD   Bolt    2   9580005-
B-Q020490-00007 1   垫圈16    Washer  9   9580005-
B-Q020750-00091 1   胶管接头8I-3200 Hose    3   9580005-
W-16-00598  1   软管总成|F7711519202020 Hose ass’y  2   9580005-
B-G057830-00075 1   螺栓M16×45-10.9ZnD    Bolt    6   9580005-
B-Q020120-00004 1   U形管夹A34 U-clip  3   9580005-
B-Q020710-00106 1   O形圈95×3.1   O-ring  1   9580005-
W-16-00137  1   软管总成|F4611515121212 Hose ass’y  4   9580005-
B-Q020140-00001 1   分离式法兰A32.6/35   Flange  16  9580005-
W-15-00107  1   O形圈|2-214N552-90    O-ring  8   9580005-
W-07-00170  1   先导阀|606-1021-1213   Precursor valve 1   9580005-
B-Q020490-00021 1   垫圈6 Washer  4   9580005-
B-G057830-00068 1   螺栓M16×30ZnD Bolt    4   9580005-
B-Q020710-00066 1   O形圈105×3.1  O-ring  1   9580005-
B-Q020710-00085 1   O形圈65×3.1   O-ring  1   9580005-
B-G008980-00015 1   螺柱M12×50-8.8ZnD Bolt    4   9580005-
B-Q020710-00050 1   O形圈32×3.1   O-ring  2   9580005-
W-07-00172  1   先导供油阀DGf-00 Valve   1   9580005-
W-07-00166  1   阀块|EMDV-C7  Valve   1   9580005-
B-G057830-00011 1   螺栓M10×35-10.9ZnD    Bolt    8   9580005-
B-G061700-00014 1   螺母M16ZnD    Nut 3   9580005-
B-G000930-00006 1   垫圈16    Washer  7   9580005-
B-G057820-00091 1   螺栓M16×80-10.9ZnD    Bolt    1   9580005-
