SBH00616 Induction & Exhaust System

1 SB15A 010 T3777U031 进气管 Inlet manifold 1 1 1 1 1 1 1 1 1 1 1 1
2 SB15A 016 T3688C028 垫 Joint 1 1 1 1 1 1 1 1 1 1 1 1
3 SB15A 020 T2314J009 螺栓 Screw 6 6 6 6 6 6 6 6 6 6 6 6
4 SB15A 022 T2314J019 螺栓 Screw 2 2 2 2 2 2 2 2 2 2 2 2
5 SB16A 001 T2313M378 双头螺栓 Stud 2 2 2 2 2 2 2 2 2 2 2 2
6 SB16A 002 T2313M387A 双头螺栓 Stud 4 4 4 4 4 4 4 4 4 4 4 4
7 SB16A 003 T2313M380A 双头螺栓 Stud 2 2 2 2 2 2 2 2 2 2 2 2
8 SB16A 004 T2318A634 螺母 Nut 8 8 8 8 8 8 8 8 8 8 8 8
9 SB16A 013 T3688C017 垫 Joint 1 1 1 1 1 1 1 1 1 1 1 1
10 SB16A 014 T36862191 垫 Joint 2 2 2 2 2 2 2 2 2 2 2 2
11 SB16A 016 T3778P051 排气管 Exhaust manifold 1 1 1 1 1 1 1 1 1 1 1 1
12 SB15E 004 T3766T131A 进气弯管 Inlet elbow 1 1 1 1 1 1
12-a SB15E 004 T3766P241 进气弯管 Inlet elbow 1 1 1 1 1 1
13 SB15E 005 T2314J003 螺栓 Screw 2 2 2 2 2 2
13-a SB15E 005 T2314J014 螺栓 Screw 4 4 4 4 4 4
14 SB15E 006 T2314J019 螺栓 Screw 2 2 2 2 2 2
15 SB15F 149 T3684N008 垫 Joint 1 1 1 1 1 1 1 1 1 1 1 1
16 AF**** T2431131 堵 Plug 1 1 1 1 1 1 1 1 1 1 1 1
17 SB15F 004 T3383E005 胶管 Hose 1 1 1 1 1 1
18 SB15F 007 T0180069A 卡箍 Clip 1 1 1 1 1 1
