CLG842 00E0026 燃油箱总成 Fuel Tank Assembly

1 06B0121 GB97.1-85 垫圈 Washer 16-140HV-Zn.D 4
2 06B0015 GB93-87 垫圈 Washer 16 4
3 00B0045 GB5782-86 螺栓 Bolt M16x50-8.8-Zn.D 4
4 04D0035 箱体 Tank body 1
5 16C0004 透气盖 Airing cap 1
6 07B0003 GB893.1-86 挡圈 Retainer ring 75 1
7 12D0072 滤筒 Cartridge 1
8 20A0633 油尺 Dipstick 1
9 12B0239 GB1235-76 O形圈 O-ring 48×3.5 1
10 05D0009 滤筒 Cartridge 1
11 06B0002 GB93-87 垫圈 Washer 10 6
12 00B0193 GB5783-86 螺栓 Bolt M10x25-8.8-Zn.D 6
13 12B0238 GB3452.1-92 O形圈 O-ring 145×3.55 1
14 52A0050 法兰盖 Flange Cover 1
15 12B0237 GB1235-76 O形圈 O-ring 40×3.1 1
16 03B0024 BF25-24 螺栓 Bolt 1
