CLG842 23E0076 空调系统 A/C System (制冷剂 Refrigerant R134a)

1 86A0084 出风口 Air vent 4
2 00B0075 GB5783-86 螺栓 Bolt M8×20-8.8-Zn.D 14
3 06B0086 GB96-85 垫圈 Washer 8-140HV-Zn.D 8
4 06B0006 GB93-87 垫圈 Washer 8 22
5 46C0820 储液罐至蒸发器管 Liquid reservoir to
evaporator pipe
1
6 46C0817 蒸发器至压缩机管 Evaporator to compressor
pipe
1
7 46C0105 水管Φ16 Water pipe Φ16 1
8 46C0104 水管Φ16 Water pipe Φ16 1
9 46C0645 蒸发器总成 Evaporator assembly 1
10 86A0127 大出风口 Big air vent 2
11 00B0007 GB5783-86 螺栓 Bolt M8×16-8.8-Zn.D 8
12 06B0005 垫圈 Washer 8-140HV-Zn.D 12
13 20A3265 弯板 Bent plate 2
14 03B0021 GB6170-86 螺母 Pipe clamp M8-8-Zn.D 2
15 09C0127 三管夹 Clamp triple pass 1
16 37B0004 尼龙扎带 Nylon tape ZD200×5 10
17 46C0300 管夹 Pipe clamp 1
18 46C0208 管夹 Joint 1
19 46C0646 电磁阀总成 Solenoid valve assembly 1
20 46C0103 水管Φ16 Water pipe Φ16 1
21 46C0816 压缩机至冷凝器管 Compressor to condenser
pipe
1
22 46C0488 暖风进水阀 Warm air inlet valve 1
23 46C0862 储液罐总成 Liquid reservoir assembly 1
24 46C0819 冷凝器至储液罐管 Condenser to liquid
reservoir pipe
1
25 00B0022 GB5783-86 螺栓 Bolt M6×16-8.8-Zn.D 2
26 06B0024 GB97.1-85 垫圈 Washer 6-140HV-Zn.D 2
27 06B0003 GB93-87 垫圈 Washer 6 2
28 46C0110 SD-5H14 压缩机 Compressor 1
29 46C0448 17-430 冷气三角皮带 V-belt of cool air 1
30 46C0308 冷凝器总成 Condenser assembly 1
31 46C0487 暖风进水阀 Warm air inlet valve 1
32 46C0301 管夹 Bent plate 1
33 09C0125 单管夹 Clamp single pass 1
34 46C0747 空调控制面板 Control panel of A/C 1
35 46C0311 新风过滤罩 Fresh air filter cover 1
