CLG862 12C0019 000 先导阀 VALVE GP-PILOT

1 03B0087 000 螺母 NUT 6
2 05B0010 000 螺柱 STUD 3
4 12B0064 000 O 形圈 O-RING 1
5 31B0003 000 线圈总成 COIL AS 2
6 03B0088 000 螺母 NUT 2
7 00B0069 000 螺栓 BOLT 2
8 03B0089 000 螺母 NUT 2
9 20A0152 000 支架 BRACKET 2
10 72A0034 000 压条 SEAL 2
11 83A0022 000 橡胶罩 BOOT 2
12 55A0094 000 轴套 BUSHING 1
13 38C0002 000 压销组 PIN 4
14 04B0029 000 螺钉 SCREW 4
15 81A0012 000 垫片 SHIM 12
16 56A0053 000 垫圈 WASHER 4
17 75A0036 000 弹簧 SPRING 2
18 12C0020 000 阀组 VALVE GROUP 2 Z
19 12C0021 000 阀组 VALVE GROUP 3 Z
20 78A0018 000 转斗阀体 VALVE BLOCK 1
21 75A0037 000 弹簧 SPRING 4
22 55A0095 000 套筒 SLEEVE 4
23 53A0047 000 压板 PLATE 4
24 38C0003 000 固定板 PLATE 1
25 20A0153 000 胶套座 SEAT 2
26 31B0004 000 线圈总成 COIL AS 1
27 07B0020 000 挡圈 SNAP RING 4
28 08B0024 000 销 PIN 2
29 81A0013 000 垫片 SHIM 4
30 56A0054 000 垫圈 WASHER 4
31 12C0022 000 阀组 VALVE GP 2 Z
32 03B0178 000 内六角螺塞 PLUG 6
33 12C0023 000 阀组 VALVE GP 1 Z
34 12C0024 000 阀组 VALVE GROUP 1 Z
35 78A0019 000 提升阀体 VALVE BLOCK 1
36 55A0096 000 导向套 GUIDE SLEEVE 1
37 75A0038 000 弹簧 SPRING 1
38 12B0379 000 O 形密封圈 O-RING 1
39 03B0090 000 螺塞 PLUG 1
40 03B0091 000 螺塞 PLUG 6
41 03B0092 000 螺塞 PLUG 1
