Description

11D0034 Boom pin for LIUGONG part

40C2440X2 00B0434 bolt GB5783-86; M16×40-10.9-DK
00E0802X1 diesel engine system; ASSY
00E0802X1 66C2206 fuel pipe; ASSY
00E0802X1 03A0777 screw; 35
00E0802X1 00A5843 connector; 35
00E0802X1 00A5829 connector; 35
00E0802X1 06B0065 Washer; 18; AGGL
00E0802X1 09C0236 Clamp; φ20～φ32, 12mm; assembly parts
00E0802X1 06C8908 Fuel pipe; ASSY
00E0802X1 00A4124 nut; 35
00E0802X1 20A1853 wire clamp; 22; assembly
00E0802X1 06C8906 Fuel pipe; ASSY
00E0802X1 00A4126 connector; 20
00E0802X1 09C0235 clamp; φ16～φ25, 12mm; assembly parts
00E0802X1 00A4123 connector; 20
00E0802X1 00A4127 nut; 35
00E0802X1 20A1854 wire clamp; 27; assembly
00E0802X1 09C0232 clamp; φ12～φ20; assembly parts
00E0802X1 66C0684 Fuel pipe; ACM
00E0802X1 35C0969 shock absorber; AGGL
00E0802X1 00A1195 connector; 35
00E0802X1 40C2420 oil-water separator; 10 MICRON-7.6L; ASSY
00E0802X1 55A4196 Spacer; Q235
00E0802X1 06B0001 Washer; GB97.1-85; 10-140HV-Zn.D; STL
00E0802X1 06B0002 Washer; GB93-87; 10; 65Mn
00E0802X1 00B0234 bolt; GB5783-86; M20×50-10.9-Zn.D; STL
00E0802X1 06B0271 Hardened washer; 45
00E0802X1 00B0064 Bolt; GB5783-86; M10×55-8.8-Zn.D; STL
00E0802X1 03B0498 Lock nut; M18; assembly
00E0802X1 06B0014 Washer; GB93-87; 18; 65Mn
00E0802X1 01B0415 Bolt; GB5782-86; M18×120-10.9-Zn.D; STL
00E0802X1 06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
00E0802X1 06B0008 Washer; GB93-87; 12; 65Mn
00E0802X1 00B0013 Bolt; GB5783-86; M12×40-8.8-Zn.D; STL
00E0802X1 40C2440X1 Intake and exhaust system; ASSY
40C2440X1 04B0177 screw; GB819-85; M6×25-4.8-Zn.D; STL
40C2440X1 85A4627 heat shield; GLASS FIBER
40C2440X1 09C1565 Turbine and worm clamp; φ150-φ170; ASSY
40C2440X1 09C1509 Turbine worm clamp; φ140-φ160; ASSY
40C2440X1 09C1528 clamp; φ175-φ187; ASSY
40C2440X1 09C1339 clamp; φ108-φ115; ASSY
40C2440X1 09C1281 clamp; φ160-φ165; ASSY
40C2440X1 00D7404 bracket; WELD
40C2440X1 06B0030 Washer; GB96-85; 10-140HV-Zn.D; STL
40C2440X1 40C2160 air pre-filter; ASSY
40C2440X1 21A3033 pressure plate; Q235
40C2440X1 06B0086 Washer; GB96-85; 8-140HV-Zn.D; STL
40C2440X1 06B0006 Washer; GB93-87; 8; 65Mn
40C2440X1 00B0020 bolt; GB5783-86; M8×30-8.8-Zn.D; STL
40C2440X1 32A1001 Air intake hose; EPDM
40C2440X1 03B0661 Nut GB6170-86; M8-10-DK
40C2440X1 01B0016 bolt; GB5783-86; M8×40-8.8-Zn.D; STL
40C2440X1 40C0319 air filter assembly; assembly parts
40C2440X1 40C1000 electronic maintenance indicator; Resistance Limit/Restriction Limit: 25″H2O/6
40C2440X1 00D6818 Air filter hoop; WELD
40C2440X1 00B0095 bolt; GB5783-86; M16×45-10.9-Zn.D; STL
40C2440X1 05D0100 Transition sleeve; welding parts
40C2440X1 20A3502 pipe clamp; Q195
40C2440X1 83A0396 Rubber sleeve; EPDM
40C2440X1 11A4126 mounting plate; Q235
40C2440X1 00B0019 bolt; GB5783-86; M10×30-8.8-Zn.D; STL
40C2440X1 00D4275 bracket; WELD
40C2440X1 10D2166 exhaust tail pipe; Q195
40C2440X1 40C0327 silencer
40C2440X1 82A0119 pad
40C2440X1 10D1611 Exhaust pipe; welding parts
40C2440X1 06B0007 Washer; GB97.1-85; 12-140HV-Zn.D; STL
40C2440X1 06B0008 Washer; GB93-87; 12; 65Mn
40C2440X1 00B0429 bolt GB5783-86; M12×40-10.9-DK
40C2440X1 06B0001 Washer; GB97.1-85; 10-140HV-Zn.D; STL
40C2440X1 85A0793 heat shield
40C2440X1 82A0879 sealing plate; EPDM
40C2440X1 03B0289 Nut; GB6170-86; M10-10-Zn.D; STL
40C2440X1 06B0002 Washer; GB93-87; 10; 65Mn
40C2440X1 00B0048 bolt; GB5783-86; M10×45-8.8-Zn.D; STL
40C2440X1 17B0046 Rubber pad; styrene butadiene rubber
00E0803X1 cooling system; ASSY
00E0803X1 06B0005 Washer; GB97.1-85; 8-140HV-Zn.D; STL
00E0803X1 03B0021 Nut; GB6170-86; M8-8-Zn.D; STL
00E0803X1 00B0020 Bolt; GB5783-86; M8×30-8.8-Zn.D; STL
00E0803X1 22A6814 support plate; Q235
00E0803X1 10A6638 Compensation gasket; Q195
00E0803X1 38A3223 Intercooler steel pipe; OCr18Ni9
00E0803X1 00D6619 bracket; WELD
00E0803X1 20A7602 pipe clamp; Q195
00E0803X1 06B0002 Washer; GB93-87; 10; 65Mn
00E0803X1 09C0232 clamp; φ12～φ20; assembly parts
00E0803X1 03B0289 Nut; GB6170-86; M10-10-Zn.D; STL
00E0803X1 00B0237 Bolt; GB5783-86; M10×35-10.9-Zn.D; STL
00E0803X1 06B0030 Washer; GB96-85; 10-140HV-Zn.D; STL
00E0803X1 06B0001 Washer; GB97.1-85; 10-140HV-Zn.D; STL
00E0803X1 15D0254 connector; welded parts
00E0803X1 09C0237 clamp; φ65～φ70; assembly parts
00E0803X1 45D1031 Protective cover; WELD
00E0803X1 09C0245 clamp; φ70～φ75; assembly parts
00E0803X1 32A0968 drain hose; EPDM
00E0803X1 00B0019 Bolt; GB5783-86; M10×30-8.8-Zn.D; STL
00E0803X1 38A3001 Intercooler steel pipe; 0Cr18Ni9
00E0803X1 00B0022 Bolt; GB5783-86; M6×16-8.8-Zn.D; STL
