1

51209153014

螺栓M24×240

Bolt M24×240

8.8

8

GB/T5784

2

16480305090

后驱动桥总成

Rear axle drive assembly

1

LG30F.04000A-1Ⅱ  283

3

60205000005

轮胎

Tires

4

GB/T2980

4

17409000001

中/后传动轴总成

Middle/rear drive shaft assembly

2

 23

5

51342000620

螺母M14×1.5

Nut M14×1.5

10

24

GB/T889.2

6

51207123118

螺栓M14×1.5×42

Bolt M14×1.5×42

10.9

20

GB/T5786

7

17401000002

前传动轴总成

Front drive shaft assembly

1

 19

8

51209153114

螺栓M24×280

Bolt M24×280

8.8

8

GB/T5784

9

30804000032

制动器右保护板焊合

Right protective plate welding of brake device

1

10

51357001119

螺母M24

Nut M24

8

16

GB/T889.1

11

16480300110

前驱动桥总成

Front drive axle assembly

1

LG30F.04000AⅡ  283

12

30804000031

制动器左保护板焊合

Left protective plate welding of brake device

1

13

30804000035

轮辋总成

Rim assembly

4

14

51421130115

垫圈16

Washer 16

4

GB/T97.1

15

51401130107

垫圈16

Washer 16

4

GB/T93

16

51204133314

螺栓M16×50

Bolt M16×50

8.8

4

GB/T5783

17

17402000001

中间支承总成

Midship mounting assembly

1

 21

18

51207121818

螺栓M14×1.5×60

Bolt M14×1.5×60

10.9

4

GB/T5786

1

37423000022

凸缘叉

Flange yoke

45

2

LGC30FQ-023

2

67426000009

弹性挡圈

Spring washer

8

LGC30FQ-026

3

67450000004

十字轴总成

Spider assembly

Φ39 × 118

2

EQ140-Ⅱ

4

67465000010

套管叉堵盖

Bushing yoke cover

1

LGC30FQ-065

5

56201000101

油杯

Oil cup

M6

1

JB/T7940.1

6

37421000001

套管叉

Bushing yoke

45

1

CDMC833Q-021

7

67411000015

密封护套总成

Sealing sleeve assembly

1

LGC30FQ-011

8

37416000001

花键轴头

Spline axon

1

CDMC833Q-016

9

67419000015

轴管

Shaft pipe

Φ89 × 4 × 178

1

LGC30FQ-019

10

37418000013

万向节叉

Universal plate

45

1

LGC30FQ-018

1

37504100101

开槽螺母

Nut

M27 × 1.5

2

LGC30FZZ-041

2

30615100823

垫圈

Washer

Φ27 × 5

2

LGC30FZZ-042

3

37490000003

凸缘

Flange

45

2

LGC30FZZ-111

4

56177012801

密封圈

Sealing ring

FB62 × 93 × 12

1

GB/T13871.1

5

51203091214

螺栓

Bolt

M8 × 30-8.8

12

GB/T5782

6

51401090107

垫圈

Washer

8

12

GB/T93

7

30810101542

轴承盖

Bearing cover

2

LGC30FZZ-092

8

52198021301

轴承

Bearing

6210

2

GB/T276

9

51512101605

销

Pin

5 × 40

2

GB/T91

10

37491000007

支承座

Support seat

1

LGC30FZZ-091

11

56201000301

油杯

Oil cup

M10 × 1

1

JB/T7940.1

12

37416000034

花键轴

Spilne shaft

1

LGC30FZZ-016
