Description

4110000763001 air filter element

4011000081 BOLT GB5783-M10*20EpZn-8.8
4015000197 WASHER GB96.1-10EpZn-300HV
29140009881 INDICATING ROD OF BUCKET
4011000145 BOLT GB16674-M14*35EpZn-8.8
4013000013 NUT GB6170-M14EpZn-8
4120001083 TILT CYLINDER HSGF-140*80*502-952P
29140011711 INDICATING PLATE OF BUCKET
29370015701 FRAME OF ADJACENT SWITCH
4011000479 BOLT GB16674-M12*30EpZn-8.8
4130000882 ADJACENT SWICH E55-D15B1
4014000042 SCREW GB818-M5*20EpZn-4.8
4015000110 WASHER GB97.1-5EpZn-300HV
4041000774 PLUG LGB13501421
4041000767 O-RING LGB168-11124
29140008441 BIG CHAMBER TUBE OF TILT CYLINDER
4030000026 O-RING GB3452.1-32.5*3.55G
4011000309 BOLT GB16674-M10*50EpZn-8.8
4011000473 BOLT GB16674-M10*55EpZn-8.8
4130000883 ADJACENT SWICH E55-D15B1/08
29370015681 BRACKET
4011000137 BOLT GB16674-M12*20EpZn-8.8
29140007551 INDICATIONG PLATE OF LIFTING CYLINDER
4041000703 TUBE LGB106-010120
4041000043 FLANGE LGB117310490
4011000475 BOLT GB16674-M10*30EpZn-8.8
4011000105 BOLT GB5783-M8*20EpZn-8.8
4015000256 WASHER GB96.1-8EpZn-300HV
29140008411 OIL TUBE OF BIG CHAMBEROF TILT CYLINDER
4030000029 O-RING GB3452.1-37.5*3.55G
4041000027 FLANGE LGB117312551
29140008401 OIL TUBE OF SMALL CHAMBEROF TILT CYLINDER
4130000869 AUXILIARY RELAY 024-1Z6GD2
4014000048 SCREW GB818-M5*12EpZn-4.8
29140004061 STEADY REST A
4041000958 U-BOLT LGB159-03040
4013000007 NUT GB6170-M10EpZn-8
4015000162 WASHER GB97.1-10EpZn-300HV
29140004071 STEADY REST B
F5-2910000950 HYDRAULIC TANK ASSEMBLY
4041000774 PLUG LGB13501421
4041000767 O-RING LGB168-11124
4011000458 BOLT GB16674-M8*20Ep.Zn-8.8
4030000232 O-RING GB3452.1-170*3.55G
29100000051 SPRING
29100000041 FLANGE CAP
29100004071 TOP OIL-SUCTION FLANGE
29100004061 STRAIN CORE
29100007641 OIL RETURNING FLANGE
4120000093 GAUGE LEVEL YWZ-200
4011000455 BOLT GB16674-M8*25EpZn-8.8
29100000361 FLANGE CAP
4120000099 BALL VALVE
29100008641 OIL-SUCTION FLANGE
4190000008 RING MAGNET LG03-CT76*32*15
4011000481 BOLT GB16674-M8*30Ep.Zn-8.8
4041000192 PLUG LGB13503341
4041000765 O-RING LGB168-12931
29100009061 FITTING
29100008551 SIDE BROAD
4011000449 BOLT GB16674-M16*35EpZn-8.8
4120000452 OIL-SUPPLYING FILTER SFM-323M
4011000461 BOLT GB16674-M8*16EpZn-8.8
4120001088 GAS-EXCHANGE FILTER L1.00807-51
29100009991 BLIND FLANGE
4030000233 O-RING GB3452.1-65*3.55G
29100009581 HYDRAULIC TANK BODY
4030000452 O-RING GB3452.1-160*3.55G
29100008361 FLANGE SEAT
4041000680 PLUGGING LGB142-03016
4030000241 O-RING GB3452.1-20.0*1.80G
4015000256 WASHER GB96.1-8EpZn-300HV
4011000106 BOLT GB5783-M8*25EpZn-8.8
F6-4120001083 TILT CYLINDER(371401)
4120000868008 BUSHING
4120000868009 COVER
4120000868010 CYLINDER BADY
4120000868011 COVERΦ25
4120000868012 COVER 52X26X11
4011000630 BOLT GB5783-M10*12-8.8
4120000868013 STEEL BALL 5
4014000059 SCREW GB70-M8*20-8.8
4120000868006 SUPPORTING RING RB132-S140*14.8*2.5
4120000868003 FABRICATE SEALING RB132-CKW1400
4120000868014 PISTON
4120000868007 SEALING MEMBER AGGREGATE
4120000868015 SCUTCHEON
4019000001 RIVET GB827-2*4-BL2
4120000868016 CYLINDER COVER
4120000868005 SUPPORTING RING RB132-G80*29.5*2.5
4120000868007 SEALING MEMBER AGGREGATE
4120000868002 SEALING RING RB132-CKS0800
4120000868004 SUPPORTING RING RB132-G80*9.5*2.5
4120000868007 SEALING MEMBER AGGREGATE
4014000147 SCREW GB70.1-M12*45EpZn-10.9
4120000868 TILT CYLINDER HSGF-140*80*502-952
4120000868001 PUSTRING 80*90*6.3/8.3
4120000868017 PISTON ROD
4120000868018 COVER
4120000868019 HOLDING BLOCK
4120000868020 SPHERICAL PLAIN BEARING
F7-4120001083 DUMP CYLINDER
4120001083102 PISTON ROD HSGF-140/80*502-1
4120000868101 SEALING MEMBER AGGREGATE
4120000868101 SEALING MEMBER AGGREGATE
4120000868101 SEALING MEMBER AGGREGATE
4120000868101 SEALING MEMBER AGGREGATE
4120000868101 SEALING MEMBER AGGREGATE
4120001083104 CYLINDER COVER HSGF-180/90*542-2
4120000868101 SEALING MEMBER AGGREGATE
4120001083106 CYLINDER BODY HSGF-140/80*502-3
4120000868101 SEALING MEMBER AGGREGATE
4120000868101 SEALING MEMBER AGGREGATE
4120000868101 SEALING MEMBER AGGREGATE
4120000868109 PISTON HSGF-140/80*502-4
4014000238 SCREW GB70.1-M8*20-8.8
4120000867121 BUSHING
4014000236 SCREW GB70.1-M12*48EpZn-10.9
4015000026 WASHER GB93-12-65Mn
4015000017 RING SNAP GB893.1-90-65Mn
4021000041 JOINT BEARING GB9163-GE60ES
4120000868101 SEALING MEMBER AGGREGATE
F8-4120000867 LIFT ARM CYLINDER（371401）
4120000867010 BUSHING
4120000867011 CYLINDER BADY
4120000867012 PISTON
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867014 PISTON ROD
4120000867018 GUIDED SET
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867019 RING SNAPφ5
4120000867007 SEALING MEMBER AGGREGATE
4120000867007 SEALING MEMBER AGGREGATE
4120000867020 SPACE RING
4014000153 SCREW GB70.1-M6*30EpZn-10.9
4015000035 WASHER GB93-6-65Mn
4120000867007 SEALING MEMBER AGGREGATE
4120000867021 RETAINER
F9-4120000867 LIFT ARM CYLINDER
4120000867102 RETAINER
4120000867103 PISTON ROD
4120000867101 SEALING MEMBER AGGREGATE
4014000153 SCREW GB70.1-M6*30EpZn-10.9
4015000035 WASHER GB93-6-65Mn
4120000867101 SEALING MEMBER AGGREGATE
4120000867101 SEALING MEMBER AGGREGATE
4120000867118 SPCER RING
4120000867119 STEEL WIRE RING SNAP
4120000867101 SEALING MEMBER AGGREGATE
4120000867105 ORIENTED SHEATH
4120000867101 SEALING MEMBER AGGREGATE
4120000867101 SEALING MEMBER AGGREGATE
4120000867101 SEALING MEMBER AGGREGATE
4120000867101 SEALING MEMBER AGGREGATE
4120000867108 CYLINDER BODY
4120000867101 SEALING MEMBER AGGREGATE
4120000867101 SEALING MEMBER AGGREGATE
4120000867101 SEALING MEMBER AGGREGATE
4014000238 SCREW GB70.1-M8*20-8.8
4120000867111 PISTON
4120000867121 BUSHING
4120000867101 SEALING MEMBER AGGREGATE
H3-2915000876 WORKING EQUIPMENT
4043000218 BUSH LGB302-60*58A2
4043000121 BUSH LGB302-60*50A2
4043000124 BUSH LGB302-85*125A2
4043000123 BUSH LGB302-65*80A2
4043000112 PIN LGB301-60*95*170G-40Cr
4043000120 PIN LGB301-85*132*245-40Cr
4043000119 PIN LGB301-60*85*150-40Cr
4043000127 PUSTRING LGB307-60
4043000056 PUSTRING LGB307-85
4043000128 PUSTRING LGB307-65
4043000126 WASHER LGB303-60*100*2
4043000125 SPACER LGB303-60*100*1
4043000129 O-RING LGB308-98*8
4030000065 GREASE NIPPLE JB7940.1-M10*1
4011000197 BOLT GB5783-M12*30EpZn-8.8
4040000001 WASHER LGB001-12*45*6
4011000094 BOLT GB5783-M16*30EpZn-8.8
4040000002 WASHER LGB001-16
29170036841 BUCKET
29170036981 LEFT SIDE BUCKET TEETH
29170036971 BUCKET TEETH
29170036961 RIGHT SIDE BUCKET TEETH
