Description
4120004771015 Seal kit 240000296S for SDLG spare parts
29360008741 提升臂位置安全标志 ARM POSITION TO ENHANCE SAFETY SIGNS
29360008541 反光标志 REFLECTIVE SIGNS
29360012861 操作机器注意标志 SAFTY-MARK BEFORE OPERATION
29360012831 安全带警告标志 SIGN FOR WEARING SEATBELTS
29360008781 铰接转向图形标志 GRAPHIC SIGNS ARTICULATED STEERING
4044000071 装载机工作装置操纵指示标志2 LGB401-G03 SIGNAGE 2 LGB401-G03
29360009511 润滑示意图 LUBRICATION DIAGRAM
29360012561 储气罐注意放水标识（英文） SIGN
29360009161 台架注意标志 NOTE BENCH MARK
29360009471 驻车制动标识 PARKING BRAKE LOGO
29360010971 动力切断选择开关标志 POWER SELECTOR SWITCH TO CUT OFF MARK
29360011451 警告标志 WARNING SIGNS
29360009171 液压油箱标志 HYDRAULIC TANK LOGO
29360011701 SDLG-800 SDLG-800
4044000018 起吊标志LGB401-F01 MARK-SLINGING-LGB401-F01
28310002241 高温警告标志 HIGH TEMPERATURE WARNING SIGNS
29360009211 机器回转警告标志 WARNING SIGNS ROTARY MACHINES
29360009221 接触机器标志 ACCSEE TO THE MACHINE MARKS
29360009191 禁止明火标志 SIGNS BAN ON OPEN FIRES
26360000121 高温油和水的注意标志 SAFETY LOGO
29360010631 防冻液标志—35 -35 ANTIFREEZE LOGO
29360010641 防冻液标志—45 -45 ANTIFREEZE LOGO
29360011501 LG968型号 MODEL LG968
29360012701 临工标志-265（白） LINGONG LOGO-265(WHITE)
29360010521 燃油箱标志 FUEL TANK MARKING
29360011751 SDLG-400 SDLG-400
29360010591 后标志 SIGNS AFTER
29360012711 临工标志-265（黑） LINGONG LOGO-265(BLACK)
29360009531 驾驶室门注意标志 ATTENTION TO THE CAB DOOR SIGNS
29360012871 电压危险标志 SIGN OF DANGEROUS VOTAGE
29360012821 规避滚翻标志 SIGNS TO AVOID ROLLING-OVER
29360010571 挡风窗喷水器标识 WATER JET WIND WINDOW
29360011741 SDLG-450 SDLG-450
29360012841 规避噪音标志 SIGNS FOR AVOIDING NOISE
29360012851 单独驾驶标志 SIGN FOR INDIVIDUAL DRIVING
2936001345001 安全标识包 SAFETY LOGOS PACKAGE
29360013451 标志与标识 SIGN AND LOGO
M6-2934001572 电瓶箱 BATTERY CASE
29340015731 电瓶箱 BATTERY CASE
29340009101 橡胶塞 RUBBER PLUG
29280000071 锁紧螺杆 BOLT OF MOUNT BAR
4013000033 螺母GB6170-M8EpZn-8 NUT GB6170-M8EpZn-8
4015000036 垫圈GB93-8-65Mn WASHER GB93-8-65Mn
4015000072 垫圈GB97.1-8EpZn-300HV WASHER GB97.1-8EpZn-300HV
29340009091 拉杆 LINK ASSEM
4015000168 垫圈GB97.1-12EpZn-300HV WASHER GB97.1-12EpZn-300HV
4016000035 开口销GB91-4*20EpZn-Q235A SPLIT PIN 4*20
29280000051 侧胶板 MAT OF PASTERN
29280000061 下胶板 MAT OF PASTERN
4190000025 扣锁NBxs1013 LOCK NBXS1013
4014000023 螺钉GB818-M5*10EpZn-4.8 SCREW
4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV
29280000081 锁紧角钢 MOUNT BAR
M7-2934001581 工具箱 TOOL CASE
29340015821 工具箱 TOOL CASE
4015000168 垫圈GB97.1-12EpZn-300HV WASHER GB97.1-12EpZn-300HV
4016000035 开口销GB91-4*20EpZn-Q235A SPLIT PIN 4*20
29340009091 拉杆 LINK ASSEM
29340009101 橡胶塞 RUBBER PLUG
4190000025 扣锁NBxs1013 LOCK NBXS1013
4014000023 螺钉GB818-M5*10EpZn-4.8 SCREW
4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV
M8-2934000206 后转向灯罩 REAR STEERING LAMP HOOD
29340002431 灯架 LAMP FRAME
4011000461 螺栓GB16674-M8*16EpZn-8.8 BOLT GB16674-M8*16EpZn-8.8
29340002442 后板 REAR PLATE
N2-2935000894 空调系统 AIR CONDITIONER SYSTEM
4011000461 螺栓GB16674-M8*16EpZn-8.8 BOLT GB16674-M8*16EpZn-8.8
4130000632 空调956-08 AIR CONDITIONER 956-08
4130000075 螺栓GB16674-M6*12EpZn-8.8 BOLT GB16674-M6*12EpZn-8.8
29350007521 压缩机支架 BRACKET
4011000447 螺栓GB16674-M10*20EpZn-8.8 BOLT GB16674-M10*20EpZn-8.8
29350007922 固定板 SUPPORT PLATE
4130000633 蒸发器总成 EVAPORATOR ASSEMBLY
4130000457 ZG30L14.05冷凝器总成 CONDENSER ASSEMBLY
4130000419 ZG30.06XG储液罐 RECEIVER
4130000420 SE5H14压缩机 COMPRESSOR ASSEMBLY
4120001513 管路：压缩机-冷凝器3000 PIPE COMPRESSOR-CONDENSER
4120001514 管路：冷凝器-储液罐2100 PIPE CONDENSER-RECEIVER
4120001515 管路：储液罐-蒸发器2100 PIPE RECEIVER-EVAPORATOR
4120001516 管路：蒸发器-压缩机3000 PIPE EVAPORATOR-COMPRESSOR
4110000302 皮带 A17-510 DRIVING BELT A17-510
O1-2937001540 电气系统 ELECTRIC SYSTEM
29370009571 启动马达线 LINE FROM SWITCH TO MOTOR
4011000461 螺栓GB16674-M8*16EpZn-8.8 BOLT GB16674-M8*16EpZn-8.8
29370014291 电瓶线A50*350 BATTERY WIRE A50*350
4130000427 电源开关K01K18-A POWER SWITCH K01K18-A
29370014261 电瓶线P50*150 BATTERY WIRE P50*150
4130000057 蓄电池6-QW-120B BATTERY 6-QW-120B
29370013101 蓄电池串联线 BATTERY CABLE
29310011841 卡子胶条 DIP RUBBER BAR
29370015301 继电器保护盒 RELAY PROTECT BOX
4014000024 螺钉GB818-M6*10EpZn-4.8 SCREW GB818-M6*10EpZn-4.8
4015000207 垫圈GB97.1-6EpZn-300HV WASHER GB97.1-6EpZn-300HV
4015000035 垫圈GB93-6-65Mn WASHER GB93-6-65Mn
4130000962 接触器JCC100/1C24·48 CONTACTER JCC100/1C24·48
4014000061 螺钉GB818-M4*10EpZn-4.8 SCREW GB818-M4*10EpZn-4.8
4015000135 垫圈GB97.1-4EpZn-300HV WASHER GB97.1-4EpZn-300HV
4015000033 垫圈GB93-4-65Mn WASHER GB93-4-65Mn
29370015291 继电器固定板 RELAY FIXATION PLANT
4190000020 扎丝LG13-ZS4*250 CLIP LG13-ZS4*250
26370001911 管夹 CLAMP
4130000009 双音盆形喇叭DL125-24V ELECTRIC HORN DL125-24V
4011000152 螺栓GB16674-M6*10EpZn-8.8 BOLT GB16674-M6*10EpZn-8.8
4130000542 前左组合灯LFLDH4-24V LEFT FRONT HEAD LAMP LFLDH4-24V
29370014021 前车架线束 FRONT BODY WIRING HARNESS
4130000543 前右组合灯LFRDH4-24V RIGHT FRONT HEAD LAMP LFRDH4-24V
4130000329 隔膜式压力开关0166-40404-1-016 PRESS SWITCH 0166-40404-1-016
29370015591 启动继电器固定板 FIXED PLATE OF STARTUP RELAY
4130000874 启动继电器SW030A3509-2 ENABLE RELAY SW030A3509-2
4014000026 螺钉GB818-M6*16EpZn-4.8 SCREW GB818-M6*16EpZn-4.8
29370015382 后车架线束 BODY WIRING HARNESS
4130001134 后尾灯LRHD-24V REAR LAMP
4130000544 后大灯SPH4-1031 REAR LARGE LAMP SPH4-1031
29370009531 后罩线束 COVER HARNESS
4130000797 前照灯QZD-2 FORWARD LIGHTING QZD-2
4130000121 倒车蜂鸣器KSHM-12F4 ANNUNCIATOR KSHM-12F4
29370015081 仪表台线束总成 PANEL HARNESS ASSEMBLY
4014000048 螺钉GB818-M5*12EpZn-4.8 SCREW GB818-M5*12EpZn-4.8
4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV
4015000034 垫圈GB93-5-65Mn WASHER GB93-5-65Mn
4013000118 螺母GB6170-M5EpZn-8 NUT GB6170-M5EpZn-8
4130000869 中间继电器024-1Z6GD2 AUXILIARY RELAY 024-1Z6GD2
29370015342 仪表盘总成Y958CAT PANEL ASSEMBLY Y958CAT
29370013341 仪表台总成 PANEL ASSEMBLY
4130000498 侧边单框架JK931-01CKJ SIDE FRAME JK931-01CKJ
4130000496 盖板JK931-01GB CAP JK931-01GB
4130000497 中间单框架JK931-01ZKJ MIDDLE FRAME JK931-01ZKJ
4130000060 手制动开关LA39-01Z HAND BRAKE SWITCH LA39-01Z
4019000026 六角螺栓3/8-16UNC-2B*20-10.9 BOLT
O2-2937001534 仪表盘总成 PANEL ASSEMBLY
4130000856 变速箱压力表350-040-005 GEARBOX MANOMETER 350-040-005
4130000858 气压表350-040-011 DIAL BAROMETER 350-040-011
4130000601 转向指示灯ZL2-ZX STEERING INDICATED LAMP ZL2-ZX
4130000498 侧边单框架JK931-01CKJ SIDE FRAME JK931-01CKJ
4130000625 指示灯组件ZL2-ZJ3 INDICATOR LAMP ASSEMBLY ZL2-ZJ3
4130000497 中间单框架JK931-01ZKJ MIDDLE FRAME JK931-01ZKJ
4130000626 指示灯组件ZL2-ZJ4 INDICATOR LAMP ASSEMBLY ZL2-ZJ4
4130000627 指示灯组件ZL2-ZJ5 INDICATOR LAMP ASSEMBLY ZL2-ZJ5
4130000628 指示灯组件ZL2-ZJ6 INDICATOR LAMP ASSEMBLY ZL2-ZJ6
4130000629 指示灯组件ZL2-ZJ7 INDICATOR LAMP ASSEMBLY ZL2-ZJ7
4130000523 水温表SWVDO WATER TEMPERATURE GAUGE SWVDO
4130000286 油温表YW201A OIL TEMPERATURE GAUGE YW201A
4130000608 仪表盘面板ZL2-MB1 PANEL ZL2-MB1
4130000875 电锁84829 ELECTRIC SWITCH LOCK 84829
4130000209 油位表RY242-2A FUEL LEVEL GAUGE RY242-2A
4130000864 转速表ZS901A(2.29) REVOLUTION COUNTER ZS901A(2.29)
4130000876 计时表85329 CHRONOMETER RATE 85329
4130000426 报警按钮开关LD62Z-050 ALARM BUTTON SWITCH LD62Z-050
4130000021 组合开关LG13-ZHK COMBINED SWTICH LG13-ZHK
4130000499 喷水开关JK931-01PS SPRAY WATER BUTTON-SWITCH JK931-01PS
4130000493 刮雨器开关JK931-01GYQ WIPER BUTTON-SWITCH JK931-01GYQ
4130000496 盖板JK931-01GB CAP JK931-01GB
4130000491 后照灯开关JK931-01HZD BACKWARD LIGHTING BUTTON-SWITCH JK931-01HZD
4130000490 前照灯开关JK931-01QZD FORWARD LIGHTING BUTTON-SWITCH JK931-01QZD
4130000494 后大灯开关JK931-01HDD REAR BIG LAMP BUTTON-SWITCH JK931-01HDD
4130000871 闪光器MFA/024-1H2 FLASH APPARATUS MFA/024-1H2
4130000587 蜂鸣器SFM-27 ALARM APPARATUS SFM-27
4130000309 保险丝盒BX2203HB-1 FUSE BOX BX2203HB-1
4130000331 备用插头8JA002262-001 STANDBY PLUG 8JA002262-001
4130000332 备用插座8JB001946-011 STANDBY SOCKET 8JB001946-011
4130000861 压力传感器360-081-030-100 PRESSURE TRANSDUCER 360-081-030-100
4130000879 过渡接头R1/4 TRANSITION JOINT R1/4
4130000860 压力传感器360-081-037-008 PRESSURE TRANSDUCER 360-081-037-008
4130000878 过滤接头M10*1 FILTERING JOINT M10*1
4130000065 变矩器油温传感器WG202A TORQUE CONVERTER OIL TEMPERATURE SENSOR WG202A
4130000887 转速传感器ZG901(M18*1.5*50) REVOLUTION SPEED TRANSDUCER ZG901(M18*1.5*50)
4130001058 水温传感器323 801 001 007N WATER TEMPERATURE SENSOR 323 801 001 007N
4130000269 油位传感器RG2268-M16A OIL LEVEL SENSOR RG2268-M16A
O3-2937001334 仪表台总成 PANEL ASSEMBLY
4120001548 方向盘LG20-FXP-01 STEERING WHEEL LG20-FXP-01
4013000096 螺母GB6171-M16*1.5EpZn-8 NUT GB6171-M16*1.5EpZn-8
4130000605 仪表盘壳体ZL2-KT SHELL ZL2-KT
4014000088 螺钉GB818-M5*16EpZn-4.8 SCREW GB818-M5*16EpZn-4.8
4015000110 垫圈GB97.1-5EpZn-300HV WASHER GB97.1-5EpZn-300HV
4190000636 可调方向机罩 HOOD
4120001002 转向器BZZ3-100 STEERING GEAR BZZ3-100
4014000164 螺钉GB819.1-M6*35EpZn-4.8 SCREW GB819.1-M6*35EpZn-4.8
4120001703 转向柱LG20-ZXZ-06 STEERING COLUMU LG20-ZXZ-06
4014000040 螺钉GB818-M6*20EpZn-4.8 SCREW GB818-M6*20EpZn-4.8
4015000207 垫圈GB97.1-6EpZn-300HV WASHER GB97.1-6EpZn-300HV
4014000026 螺钉GB818-M6*16EpZn-4.8 SCREW GB818-M6*16EpZn-4.8
4011000320 螺栓GB16674-M12*40EpZn-8.8 BOLT GB16674-M12*40EpZn-8.8
4190000831 958可调仪表盘骨架 FRAME
4011000474 螺栓GB16674-M10*25EpZn-8.8 BOLT GB16674-M10*25EpZn-8.8
