Description
4120004876 hose for SDLG spare parts
29120015911 COVER PS
29120016101 OIL RETURN PIPE OF PUMP
29120015221 WASHER
29120010831 FRONT PILOT PTPE（a1）
29120015401 FITTING
29120007671 CLAMP
29120016011 MOUNTED PLATE
4041000774 PLUG LGB13501421
4041000632 PIPE LGB125-004080
29120015081 JOINT
4030000276 O-RING GB3452.1-32.5*2.65G
4120001954 STRAINER
29120016021 PLATE
4041000150 STAIGHT JOINT LGB120-01814
29120007561 OIL RETURN PIPE OF SELECTION VALVE
29120007551 INLET OIL PIPE OF SELECTOR VALVE
4120000448 PRESSURE SELECTION VALVE SF8-C
29120016741 CLAMP
29120016951 MOUNTED PLATE
29120016351 MOUNTED PLATE
4190000020 CLIP LG13-ZS4*250
29120017441 PIPE (b2-2A)
29120017431 PIPE (b1-1A)
4041001047 CONNECTOR LGB143-01406
4030000530 O-RING GB3452.1-6.00*1.80G
4041001223 HOSE LGB125-003060
4041000027 FLANGE LGB117312551
4041000716 DUST-PREVENTION CAP
29120014792 FRONT COVER PLATE
29120017411 PIPE (a1-1B)
29120017421 PIPE（a2-2B)
29120018541 OIL INLET BLOCK
29110000021 HOSE
29110007561 OIL INLET TUBE OF WORKING PUMP
4030000235 O-RING GB3452.1-43.7*3.55G
4041000011 FLANGE LGB117-314650
4120000903 WORKING PUMP CBGj3100C
29110007541 SEAL SPACER OF PUMP
29110001021 OUT-OIL TUBE
4030000029 O-RING GB3452.1-37.5*3.55G
4041000056 FLANGE LGB117-312550
4041000055 PIPE LGB106-012085
29110008841 TEE BLOCK
4041000774 PLUG LGB13501421
4041000767 O-RING LGB168-11124
29110009081 PIPE
4120000600 LIFTING CYLINDER HSGF-180*100*798-1348
29130012441 SMALL CHAMBER TUBE OF LEFT LIFT ARM CYLINDER
4030000026 O-RING GB3452.1-32.5*3.55G
29130010861 THREE-WAY OIL TUBE
4030000029 O-RING GB3452.1-37.5*3.55G
29130010891 OIL TUBE OF LIFTING CYLINDER (L)
29130012111 LEFT BEARER
29130010961 OIL TUBE OF LIFTING CYLINDER (L)
29130011001 BRACKET
29130010981 THREE-WAY OIL TUBE
4041001141 U-BOLT LGB159-03646
4041001142 PADDING LGB160-3646
4041000958 U-BOLT LGB159-03040
4041001018 PLATE LGB160-3040
29130010571 OIL PIPE OF LIFTING CYLINDER
4041000043 FLANGE LGB117310490
29130000111 CLAMP
29130000051 OIL TUBE TO BIG CHAMBER OF RIGHT LIFTING CYLINDER
29130010371 CLAMP
4041000869 CUSHION LGB123-0740
29130000031 OIL TUBE TO BIG CHAMBER OF LEFT LIFTING CYLINDER
29130010941 OIL TUBE OF LIFTING CYLINDER (R)
29130010921 OIL TUBE OF LIFTING CYLINDER (R)
29130012461 RIGHT LIFTING CYLINDER SMALL CHAMBER TUBE
