Description

60A0036 spring pin for liugong part

00C1815 Working pump pipeline
12B1162 O-ring 02130, 130×3.1
00B0386 Bolt M12×35-10.9-Zn.D
06B0397 Washer 31232
11C0743 working pump
00A3414 connector 1KG-14-04
00B0237 Bolt M10×35-10.9-Zn.D
06B0447 Washer 10
03B0975 Screw plug 30108, R1/8
10D3536 steel pipe assembly
12B1145 O-ring 03032, 32×3.5
00B0239 Bolt M12×40-10.9-Zn.D
06B0415 Washer 12
12B1140 O-ring 02060, 60×3.1
11C0676 working pump
12B1169 O-ring 13038, 38×3.5
01A1787 Elbow joint
06B0396 Washer 31032
01B0651 Bolt M10×85-10.9-Zn.D
10D3491 Steel pipe assembly
12B1169 O-ring 13038, 38×3.5
06B0428 Washer 51032, 10
04A1252 flange clamp 07371-31255
00B0237 Bolt M10×35-10.9-Zn.D
07C1473 Hose assembly
06B0396 Washer 31032
01B0647 Bolt M10×70-10.9-Zn.D
12C1608 Multi-way valve assembly
01B0651 Bolt M10×85-10.9-Zn.D
01B0862 Bolt 01010-51095M10×95-10.9-Zn.D
10D6051 steel pipe assembly
05C1941 Hose assembly 07102-20212
21C0291 hydraulic oil tank
00B0341 Bolt M10×25-10.9-Zn.D
06B0396 Washer 31032
03B1121 Screw plug 13620, M36×1.5
12B1333 O-ring 13634, 32.7×3.4
06B0399 Washer 32060
00B0356 Bolt M20×40-10.9-Zn.D
10D3354 steel pipe assembly
12B1316 O-ring 05155, 155×5.7
53A0092 Flange cover ZL50G.10.11-1
02A0749 Through the oil block
01B0473 Bolt M10×110-10.9-Zn.D
00A3414 connector 1KG-14-04
06B0008 Washer 12
00B0239 Bolt M12×40-10.9-Zn.D
12B1140 O-ring 02060, 60×3.1
10D3470 steel pipe assembly
06B0395 Washer 30823
00B0655 Bolt M8×25-10.9-Zn.D
16C0042 Air Filter EF4-50
04D0720 box
53C0553 Return oil filter RF-500×10F
44C0017 Liquid Level and Temperature Gauge YWZ-150T
10D4059 steel pipe assembly
12B1145 O-ring 03032, 32×3.5
06B0002 Washer 10
00B0237 Bolt M10×35-10.9-Zn.D
38A2863 steel pipe
04A1250 Flange pressure plate 07371-3104907371-31049
07C2624 Hose assembly 07297-01008
07C2625 Hose assembly 07296-01009
15B0123 Throat clamp 00419，30～40
30A0781 Suction hose
15B0095 Throat clamp 60-80
12B1167 O-ring 13032, 32×38×3.5
01A1713 Elbow joint
30A0735 Suction hose 07260-05820
00B0244 Bolt M16×40-10.9-Zn.D
06B0398 Washer 31645
00D3414 bracket
03B0290 Nut M12-10-Zn.D
10D6050 steel pipe assembly
37B0004 Nylon cable tie ZD200×5
12B1146 O-ring 03035, 35×3.5
44C0992 Pilot hydraulic system pipeline
10D6107 steel pipe assembly
80A0752 Combination seal ZHD-27
03A0766 Hinge bolt
20C0872 Hydraulic Oil Radiator XGYS01-14
01B0889 Bolt M8×70-10.9-Zn.D
06B0395 Washer 30823
03B0087 Nut M8-10-Zn.D
00A3414 connector 1KG-14-04
04B0194 screw M6×25-10.9-Zn.D
03B0036 Nut M6-8-Zn.D
06B0474 Washer 30623, 6
37C0605 clip
00B0257 Bolt M8×20-10.9-Zn.D
05C1946 Hose assembly 07108-20208
00A3423 connector 1KG-22-08
05C1943 Hose assembly 07108-20209
06C4338 Hose assembly 07108-20410
00A3399 Right angle connector 1KG9-22-08OG
12C1719 Unloading valve PCMM10001
83A0913 Rubber pad WD-B04
00A3404 connector
83A0914 Rubber pad WD-B12
15C0235 Accumulator NXQA-0.63/10-L
12C1707 Blade control valve PCL401-04-HK15-002
12C1708 Scarifier control valve PCL401-04-HK15-001
05C1944 Hose assembly 07108-20207
01A1763 Transition joint 2K9-14
02A0742 Tee connector AKKG-14-14-04OG
37B0004 Nylon cable tie ZD200×5
06C7127 Hose assembly 07102-20450
06B0396 Washer 31032
03B0289 Nut M10-10-Zn.D
00B0237 Bolt M10×35-10.9-Zn.D
29A0174 Bent plate
00B0386 Bolt M12×35-10.9-Zn.D
06B0397 Washer 31232
44C0536 Blade Lifting Pipeline
12B1171 O-ring 13048, 48×3.5
12C2001 Valve 195-63-14002(LG) 195-63-14002(LG)
12B1172 O-ring 12055, 55×60×3.1
12B1169 O-ring 13038, 38×3.5
12B1170 O-ring 13045, 45×3.5
04A1250 Flange pressure plate 07371-3104907371-31049
12B1167 O-ring 13032, 32×38×3.5
02A0677 Connector block
06B0397 Washer 31232
01B0386 Bolt M12×80-10.9-Zn.D
03B0290 Nut M12-10-Zn.D
00B0213 Bolt M16×120-10.9-Zn.D
07C1496 Hose assembly 07088-01015
18A1822 block
00D3232 Mounting seat
06B0396 Washer 31032
00B0331 Bolt M10×30-10.9-Zn.D
03B0093 Screw plug ZL50C.10.18-1
12B1330 O-ring 11423, 10.9×2.3
15D0565 flange block
12C1724 solenoid valve D3W21KNJWD3W21KNJW
10D3521 steel pipe assembly
10D3520 steel pipe assembly
00B0524 Bolt M10×40-10.9-Zn.D
10D3517 steel pipe assembly
12B1174 O-ring 12434, 20.7×3.4
31C0548 Right angle connector 07235-1052207235-10522
01B0215 Bolt M10×60-10.9-Zn.D
06B0428 Washer 51032, 10
12B1168 O-ring 13035, 35×3.5
10D3518 steel pipe assembly
01B0641 Bolt M10×65-10.9-Zn.D
21A4186 pipe clamp
17D0368 pipe clamp
07C1490 Hose assembly 07089-01012
07C1489 Hose assembly 07089-01013
63A0229 U-shaped pipe clamp 07283-23442 07283-23442
03B0952 Nut M10×1.25-10-Zn.D
06B0398 Washer 31645
00B0386 Bolt M12×35-10.9-Zn.D
22A2527 Bent plate
35C0708 pipe clamp
04B0589 screw M6×40-10.9-Zn.D
06C4371 Hose assembly 07086-00527
07C1494 Hose assembly 07088-01021
00B0237 Bolt M10×35-10.9-Zn.D
01B0395 Bolt M12×70-10.9-Zn.D
10C0857 Blade Lifting Cylinder 10C079410C0794
44C0537 Blade tilt pipe
12B1308 O-ring 13030, 30×3.5
16A4448 block
06B0428 Washer 51032, 10
01B0215 Bolt M10×60-10.9-Zn.D
01B0647 Bolt M10×70-10.9-Zn.D
00B0524 Bolt M10×40-10.9-Zn.D
00B0563 Bolt M10×50-10.9-Zn.D
45D0489 cover
06B0416 Washer 31445, 14
00B0366 Bolt M14×35-10.9-Zn.D
06C4378 Hose assembly 07086-00605
45D0490 cover
00B0188 Bolt M14×40-10.9-Zn.D
12A2263 washer
45D0491 cover
06B0399 Washer 32060
00B0234 Bolt M20×50-10.9-Zn.D
17D0374 pipe clamp
01B0395 Bolt M12×70-10.9-Zn.D
12B1168 O-ring 13035, 35×3.5
10D3519 steel pipe assembly
06C4355 Hose assembly 07086-00612
10D3590 steel pipe assembly
10D3524 steel pipe assembly
10D3523 steel pipe assembly
10D3522 steel pipe assembly
00B0238 Bolt M12×30-10.9-Zn.D
45D0493 cover
06B0397 Washer 31232
45D0492 cover
06C4377 Hose assembly 07086-00606
17D0431 pipe clamp
00B0103 Bolt M14×50-10.9-Zn.D
10D3525 steel pipe assembly
10D3526 steel pipe assembly
21A4648 pipe clamp
00B0566 Bolt M14×20-10.9-Zn.D
10D3528 steel pipe assembly
10C0795 Tilt cylinder
10D3527 steel pipe assembly
23A6687 Bent plate 175-61-18162 175-61-18162
72A1102 Cover 175-71-31321175-71-31321
72A1103 Cover 175-71-31331175-71-31331
11E0457 Ripper pipe
12B1168 O-ring 13035, 35×3.5
06B0396 Washer 31032
04B0151 Screw M10×45-10.9-Zn.D
17D0372 pipe clamp
11A3626 pipe clamp
06B0395 Washer 30823
00B0540 Bolt M8×30-10.9-Zn.D
04A1250 Flange pressure plate 07371-3104907371-31049
00B0237 Bolt M10×35-10.9-Zn.D
06B0428 Washer 51032, 10
12B1167 O-ring 13032, 32×38×3.5
00D3620 bracket
17D0368 pipe clamp
01B0648 Bolt M10×80-10.9-Zn.D
00D3619 bracket
00D3540 bracket
01B0215 Bolt M10×60-10.9-Zn.D
06C4368 Hose assembly 07088-21018
10C0801 Tilt cylinder
06C4369 Hose assembly 07088-21020
06C5141 Hose assembly 07088-21015
10C0808 Lifting cylinder
00B0236 Bolt M10×20-10.9-Zn.D
11A3558 pipe clamp 07282-13411
10D3460 steel pipe assembly
10D3463 steel pipe assembly
10D3461 steel pipe assembly
10D3462 steel pipe assembly
03A0473 Through oil block
07C1496 Hose assembly 07088-01015
10D3465 steel pipe assembly
10D3464 steel pipe assembly
10D3467 steel pipe assembly
10D3466 steel pipe assembly
