Description

72A0301 Bucket tooth sleeve for LIUGONG spare part

SP125996 19STB1001 轮壳盖 COVER
SP125997 19STB1002 轴端挡圈 SNAP RING
SP125998 19STB1003 调整垫 SHIM
SP125999 17ZUJ1001 转向轮壳 HOUSING
MS105067 轴承32010；GB/T297-94 BEARING
MW102519 骨架油封55×80×10；GB9877.1-92 SEAL
SP126000 17ZUJ1002 转向桥体 AXLE BODY
SP126001 19STB1006 转向轮轴 SHAFT
SP126002 19STB1007 轮胎螺栓 BOLT
SP126003 AE 3519 A0 骨架油封70×92×12 SEAL
MW102520 O形圈Φ40×1.8；GB3452-92 O-RING
MW101385 单列圆锥滚子30309；GB/T297-94 ROLLER
SP126004 AE 3932 A9 骨架油封90×115×13 SEAL
平键12×40×8；GB1096-79 SPLINE
SP125832 耐磨环 WEAR RING
SP125833 UHS50 油封50×60×7 SEAL

ZL30E 47E0017X3 (ZL30E warm air) 47C0032 door (left) 1
47C0040 Right door 1
47E0016X3 (ZL30 air conditioner) 84A0053 Front window sealing strip 1
41E0200X0 (ZL30E air conditioner, export type) 84A0054 Rear window sealing strip 1
84A0055 Right window rubber strip 1
84A0105 left window rubber strip 1
87A0010 side window glass 2 ZL40B.17-7
87A0011 Front window glass 1 ZL40B.17-8
87A0012 Rear window glass 1 ZL40B.17-9
87A0020 Right door glass 1 ZL40B.17.5-3
87A0018 Left door movable window glass 1
87A0019 Left door fixed window glass 1
34C0085 lock 1
47C0033 Window (Left Door) 1 ZL40B.17.4.2 Window includes movable window glass: 87A0018; fixed window glass: 87A0019, etc.; left hand: 47C0037; right hand: 47C0038, etc., currently movable window: 87A0018; fixed Window glass: 87A0019 has no single purchase.
47C0037 Left knob 1
47C0038 Right knob 1
84A0066 sealing strip 2
“ZL40B

ZL50C” 47C0017X0 (for 50C) 87A0020 Door glass (right door) 1 Material: HM006; L=3970
47C0017X2 (for 50C side unloading) 87A0011 Front window glass 1 ZL40B.17-8
87A0011 Rear window glass 1 ZL40B.17-9
87A0010 Side window 2 ZL40B.17-7 L=944.8X332.8
84A0105 Left window rubber strip 1 ZL40B.17-5; Material: Rubber V-2
47C0017X8 (for 40B) 84A0055 Right window rubber strip 1 ZL40B.17-16; material: rubber V-2
47C0017X8+36D0019 (for 40B side unloading) 84A0053 Front window sealing strip 1
84A0054 Rear window sealing strip 1 The window includes movable window glass: 87A0018; fixed window glass: 87A0019, etc.; left handle: 47C0037; right handle: 47C0038, etc., currently movable window glass: 87A0018; fixed window glass: 87A0019. No single purchase .
84A0071 Glass glue strip (right door) 1 ZL40B.17.5-4; Material: Rubber V-2 MX110027 uses SP117509 (Note: also glass glue strip)
84A0513 Right door sealing strip 1 ZL40B.17.4.2
84A0512 Left door sealing strip 1 Material: HM006; L=3140
47C0032 Door (left) 1
47C0033 Window (Left Door) ZL40B.17.5-3
47C0037 Left knob 1
47C0038 Right knob 1
87A0018 movable window glass 1
87A0019 fixed window glass 1
34C0085 Left door lock 1
ZL50E 41E0020X0 87A0010 side window glass 2
84A0105 left window rubber strip 1 ZL40B.17-5
87A0011 Front window glass (Note: 87A0095 will be used after August 2003) 1
84A0053 Front window sealing strip 1 ZL40B.17-12
87A0096 rear window glass 1
84A0054 Rear window sealing strip 1 ZL40B.17-13
47C0033 Window (Left Door) 1 ZL40B.17.4.2 Window includes movable window glass: 87A0018; fixed window glass: 87A0019, etc.; left hand: 47C0037; right hand: 47C0038, etc., currently movable window: 87A0018; fixed Window glass: 87A0019 has no single purchase.
87A0020 Door glass (right door) 1 ZL40B.17.5-3
84A0071 Glass glue strip 1 ZL40B.17.5-4
CLG852 41E0047X0 87A0100 Front glass 1
87A0102 Right front glass 1
87A0104 Left front glass 1
87A0099 rear glass 1
87A0101 Right rear glass 1
87A0103 left rear glass 1
47C0173 Form (left door) 1 Only form to buy
87A0105 Right door glass 1
CLG855 41E0092X0 87A0024 Front glass 1
87A0174 rear glass 1
87A0026 Right front side glass 1
87A0025 Left front side glass 1
87A0027 Right rear side glass 1
87A0023 left rear side glass 1
47C0605 Right door 1 Right door spare parts
87A0028 Door glass 1
87A0029 Right door lower glass 1
84A0495 Door rubber strip 1
47C0526 Door lock 1
47C0431 Positioning lock 1
47C0065 Door lock 1
47C0066 Positioning lock 1
47C0604 Left door 1 Left door spare parts
84A0495 Door rubber strip 1
87A0028 Door glass 1
87A0029 Right door lower glass 1
47C0432 Door lock 1
47C0431 Positioning lock 1
47C0068 Door lock 1
47C0066 Positioning lock 1
